Prekės aprašymas
Specifikacijos
Tiekėjo prekės aprašymas
- 2*1000Mbps SFP Slots
- 8*10/100/1000Mbps Ethernet PoE ports
- Port 1-8 support IEEE802.3at/af/bt.
- Support Perpetual PoE and PoE watchdog
- Total PoE power budget is 480W, max PoE power for single port is 90W
| Model | UTP7308GE-BTPoE | |
| Physical Port | ||
| Downlink Ports | 8*10/100/1000Base-T (PoE) | |
| Uplink Ports | 2*1000Base-X SFP Slots | |
| Alarm Output | One channel relay alarm output, 1A@DC 12V, 2 cores, 5.08mm terminal | |
| LED Indicator | 8*Link/Act (Green), 8*PoE (Orange), 1*PWR (Red) | |
| Switching Feature | ||
| Standard and Protocols | IEEE802.3 , IEEE802.3u, IEEE802.3ab, IEEE802.3Z, IEEE802.3X, IEEE 802.1D, IEEE 802.1af/at/bt | |
| Switching Capacity | 20Gbps / non-blocking | |
| Packet Forwarding Rate | 14.9Mpps | |
| Packet Buffer | 4Mbit | |
| MAC Address Table | 16K | |
| Jumbo Frame | 10K bytes | |
| PoE | ||
| PoE Standard | 802.3af/at/bt(PSE) | |
| PoE Line Pair | 1/2/4/5(+)，3/6/7/8(-) | |
| PoE Output Power | PoE output power for singe port≤90W, Total PoE power budget≤480W | |
| Power Supply | ||
| Input Voltage | DC 48V-57V | |
| Power Consumption | ≤20W (Not inlcude PoE) | |
| Environment | ||
| Surge Immunity | 6KV Execute: IEC61000-4-5 | |
| ESD Immunity | 6KV: Contact discharge | |
| 15KV: Air discharge | ||
| Execute: IEC61000-4-2 | ||
| IP Grade | IP40 | |
| Operating Temperature | -10-55℃ | |
| Storage Temperature | -40-85℃ | |
| Operating Humidity | 5%-95% (Non-condensing) | |
| Physical Parameter | ||
| Dimension（L×W×H） | 159mm×110mm×46.5mm | |
| Weight | 1558g±20g | |
| Material | Aluminium alloy | |
| Installation | DIN rail / Wall mounted | |
| Number of Fans | N/A | |
| Certification | CE, FCC | |
| Software Specification | ||
| PoE Management | Perpetual PoE: The PoE is kept enabled and supplying power to PD even if you press the “reboot” for the switch, which reduces the problem of PD power failure caused by restart. | |
| Support total power consumption control | ||
| Support PoE ON/OFF | ||
| Support priority of port output power | ||
| Port | Support port isolation and rate settings | |
| Support port storm suppression | ||
| Support IEEE802.3x flow control | ||
| Support port adaptation and traffic statistics | ||
| LACP | Static LACP, Dynamic LACP | |
| VLAN | Support 4K VLAN | |
| Support 802.1Q Protocol-based VLAN | ||
| Support Port-based VLAN | ||
| QoS | Support QoS congestion management | |
| Support 8 hardware priority queues | ||
| Support WRR | ||
| Support 820.1P and DSCP priority | ||
| ERPS | STP/RSTP | |
| Fast-ring | ||
| DHCP | Support DHCP server | |
| Support DHCP snooping | ||
| Support DHCP relay | ||
| IGMP | Support IGMP SnoopingV1/V2 | |
| Security | Support RADIUS authentication | |
| Support 802.1X authentication | ||
| System Management | Support WEB management, configuration through Telnet, SSH | |
| Support FTP/TFTP/HTTP upgrading | ||
| Support MAC address tables and traffic statistics | ||
| Support IP address, DNS server change | ||
| Support username& password change | ||
| Support history record, journal management | ||
| Support system settings backup | ||
| Support factory default settings and restart | ||
